High-Temp Brass Cable Gland, Silicone Seal (-60°C to 250°C)

Our IP68 brass cable gland with a silicone seal operates from -60°C to 250°C. Perfect for extreme temperatures in automotive, marine, and outdoor lighting applications. TUV, CE, RoHS certified for reliability.

Parametri tecnici

Product Name: High Temperature Brass Cable Gland
Materiale del corpo: Nickel-Plated Brass
Claw: Silicone Rubber
Seal & O-Ring: Silicone Rubber
Protection Rating: IP68
Operating Temperature: -60°C to +250°C
Standard Sizes: M8 to M63
Certifications: TUV, CE, RoHS, IP68, ISO9001

Key Features

Extreme Temperature Range: Engineered with a full silicone rubber seal and claw, allowing it to perform flawlessly in extreme temperatures from -60°C to +250°C.
IP68 Waterproof Protection: Provides a superior waterproof and dust-tight seal, ensuring maximum protection for connections in severe outdoor and marine environments.
Durable Brass Construction: The body is made from high-quality nickel-plated brass, offering excellent corrosion resistance and mechanical strength.
Versatile Application: Ideal for demanding applications such as automotive wiring, marine equipment, outdoor lighting, refrigeration, and industrial sensors.
Fully Certified: Meets stringent international standards, with CE, TUV, RoHS, and ISO9001 certifications for guaranteed quality and safety.

Codice	Thread AG	Cable range (mm)	Thread O.D.(mm)	(mm) Mounting hole diameter	(mm) Thread length GL	Joint length (mm)	(mm) Spannersize
M8-SI	M8X1	5.5-2	8	8-8.2	5	16	12
M12A-SI	M12X1	6.5-3	12	12-12.2	7	19	14
M12B-SI	M 12X1.25	8-3	12	12-12.2	7	16	16
M12C-SI	M12X1.5	8-3	12	12-12.2	7	16	16
M14-SI	M 14X1.5	8-3	14	14-14.2	7	16	16
M16-SI	M16X1,5	9-4	16	16-16.2	8	20	20/18
M18-SI	M18X1.5	10-5	18	18-18.2	8	20	20
M20-SI	M20X1.5	12-8	20	20-20.2	8	21	24
M25-SI	M25X1.5	18-15	25	25-25.2	9	23	30
M32-SI	M32X1.5	22-18	32	32-32.2	10	26	35
M40-SI	M40X1.5	30-25	40	40-40.2	11	30	45
M50-SI	M50X1.5	38-35	50	50-50.2	12	32	55
M63-SI	M63X1.5	44-38	63	63-63.2	13	35	68
